Product Name NMN Insulating Paper NMN100/C is a kind of flexible insulation paper which is comprised of two layers ofDuPont Nomex brand paper and a layer of polyester film.

Product Description

1. Introduction juction
NMN100/C is a kind of flexible insulation paper which is comprised of two layers ofDuPont Nomex brand paper and a layer of polyester film.

2 . Features
●Superior thermal properties and mechanical properties.
●Tearing resistance as well as the excellent dielectric strength.
●Insulation Class is H~C(180℃~220℃)

3 . Application
It is suitable for insulation of slot,phase,turn-to-turn and liner of H~C class motors and generators.

4 . Test methods
All test should be in accordance with the GB/T5591.2-2002.

5 . Packing
Each roll shall be wrapped by plastic bag and packed by paper box.

6 . Storage
●NMN100/C should be stored in dry and clean environment at room temperature
●Keep away from fire,heat and directly sunshine
●After 12 months of storage, it should be tested and pass all specification before use
